CHEMICAL PROCESSING AND PAINT
PROCESS
| Process | Specification | Type | Class | Other |
|---|---|---|---|---|
| Cadmium Plate | AMS-QQ-P-416 | TYPE I CLEAR TYPE II GOLD |
CLASS 1 0.0005” MIN THICK CLASS 2 0.0003” MIN THICK |
RPS-1 ASTM B766 MIL-STD-870 AMS 2400 |
| Zinc Plate | ASTM B633 | TYPE II TYPE III |
CLASS FE/ZN25 SC4 25 MIN THICK CLASS FE/ZN12 SC3 12 MIN THICK CLASS FE/ZN8 SC2 8 MIN THICK CLASS FE/ZN5 SC1 5 MIN THICK | AMS 24000 |
| Passivate | ASTM 2700 ASTM A 967 | TYPE 2 …NITRIC 1 TYPE 6 …NITRIC 2 | AMS-QQ-P-35 | |
| Chemical Film | MIL-DTL-5541 | TYPE I TYPE II (RoHS Compliant) | CLASS 1A CLASS 3 | RPS-40 MIL-DTL-81706 AMS 2473 |
| Anodize | MIL-A-8625 | TYPE II SULFURIC 0.0007-0.0010’ THICK TYPE III HARD 0.0002-.004” THICK | CLASS 1 CLEAR CLASS 2 DYED | RPS-33 |
PRIME, PAINT, DRY LUBE
Priming and painting is a very large part of our business. We are familiar with and carry the latest specifications for MIL-Spec procedures, prime, paints and dry lubes. We also follow the AS9100 specification for quality in the aerospace community.
The following is a list of some primers, paints and dry lubes we have in stock at all times:
- MIL-PRF-23377, TYPE I & TYPE II
- PRETREATMENT WASH PRIMER MIL-C-8514
- MIL-PRF-85582
- MIL-P-53022, MIL-P-53030
- TT-P-1757
- MIL-PRF-85285M #36375, 36270, 37038, 17925, 26270
- MIL-DTL-64159, #34031, 383, 37030, 686
- MIL-DTL-53039, #34031, 383, 37030
- MIL-L-46010 – MIL-PRF-46010, AS5272
- MIL-L-23398
AND MANY MORE – IF WE DON’T HAVE IT IN STOCK, WE CAN GET IT!
